Power
Two Zone PA Amplifier
Part of the CKS amplifiers family, engineered for commercial, industrial, auditoriums applications.
- Models
- 2
- Family
- Amplifiers
- Applications
- 3
- Made in
- India
Models
2 models in this type.
Specifications are transcribed from the CKS catalogue. Open any model for its full technical detail, or carry it straight into an enquiry.
CTZ-5000
The 500W two-zone amplifier, same independent zone control on a 24V DC fallback.
- Frequency response
- 50Hz-15KHz ±3dB per zone
- Power output per channel
- 300W + 300W RMS Max
- @ 10% THD
- 250W + 250W RMS
CTZ-7000
700W two-zone amplifier letting one operator set independent levels for two areas, such as indoors and outdoors.
- Frequency response
- 50Hz-15KHz ±3dB per zone
- Power output per channel
- 500W + 500W RMS Max
- @ 10% THD
- 350W + 350W RMS
Compare
Side by side.
The specifications every model in this type shares, so the choice can be made on the numbers.
| Model | Power output per channel | @ 10% THD | @ 5% THD | @ 2% THD | Input channel | Frequency response | Speaker output | Digital player | Power supply | Dimension | Weight | Details |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CTZ-5000 | 300W + 300W RMS Max | 250W + 250W RMS | 200W + 200W RMS | 175W + 175W RMS | 6 x Mic 0.6mV/4.7KΩ, 2 x Aux 100mV/470KΩ | 50Hz-15KHz ±3dB per zone | 4Ω, 8Ω, 70V, 100V Line for each zone | Mp3 with USB, SD card and Bluetooth | AC 220-240 50/60Hz, DC 24V (2 x 12V car battery) | W 512 x H 180 x D 390 | 24Kg | Details for CTZ-5000 |
| CTZ-7000 | 500W + 500W RMS Max | 350W + 350W RMS | 300W + 300W RMS | 280W + 280W RMS | 6 x Mic 0.6mV/4.7KΩ, 2 x Aux 100mV/470KΩ | 50Hz-15KHz ±3dB per zone | 4Ω, 8Ω, 70V, 100V Line for each zone | Mp3 with USB, SD card and Bluetooth | AC 220-240 50/60Hz, DC 36V (3 x 12V car battery) | W 512 x H 185 x D 475 | 40Kg | Details for CTZ-7000 |
