Two Zone PA Amplifier · Amplifiers
CTZ-7000
700W two-zone amplifier letting one operator set independent levels for two areas, such as indoors and outdoors.
- Frequency response
- 50Hz-15KHz ±3dB per zone
- Weight
- 40Kg
- Power output per channel
- 500W + 500W RMS Max
- @ 10% THD
- 350W + 350W RMS
Manufactured in Gandhinagar, Gujarat. Specifications transcribed from the CKS 2026 catalogue.
Alternatives
Others in this range.
Models an integrator would weigh against CTZ-7000, nearest first. All two zone pa amplifier
Specification
Every published figure.
| Power output per channel | 500W + 500W RMS Max |
|---|---|
| @ 10% THD | 350W + 350W RMS |
| @ 5% THD | 300W + 300W RMS |
| @ 2% THD | 280W + 280W RMS |
| Input channel | 6 x Mic 0.6mV/4.7KΩ, 2 x Aux 100mV/470KΩ |
| Frequency response | 50Hz-15KHz ±3dB per zone |
| Signal to noise ratio | 60dB |
| Speaker output | 4Ω, 8Ω, 70V, 100V Line for each zone |
| Digital player | Mp3 with USB, SD card and Bluetooth |
| Power supply | AC 220-240 50/60Hz, DC 36V (3 x 12V car battery) |
| Dimension | W 512 x H 185 x D 475 |
| Weight | 40Kg |
