MPA 2600

Description

Two channel power amplifier designed for high end entertainment sound reinforcement.

• Rear mounted switch for level controls for each channel

• MPA Series sufficient & powerful output capacity at 8 Ohms, 4 Ohms & 2 Ohms.

• Two high speed cooling fans for adequate cooling & allow extended use.

• Balanced XLR and Speckon Outputs

• Highly efficient, reliable & no interference for premium loud speaker system

• 3U models features 1200W to 3600W per channel @ 4 Ohms

• Advance protection circuit for protect from overload, over temperature, short circuit DC shock and frequency.

8Ω stereo power 2x550W

4Ω stereo power 2x950W

2Ω stereo power 2 x1300W

8Ω Bridge Mono power 1900W

4Ω Bridge Mono power 2600W

Frequency Response 20HZ-20KHZ ‡0.1 db-0.3db 1W/8Ω



THD + N (80HM 1 KHz IN ¼ OUTPUT) <0.05%



Signal Noise Ratio (dB) >95dB



Damping Factor (8[], 20Hz-1 KHz) >400



Input connectors (per ch.) 3-pin XLR, electronically balanced



Link connectors (per ch.) XLR, 3 pin male



Input Impedance 20KΩ Balanced, 10KΩ Unbalance



Output topology Class AB



Dimensions (mm) W 483 x H 146 X D 460

Weight 29.00 Kg
